The AGV Battery 48V 30Ah is a 51.2-volt LiFePO4 pack of 1,536 watt-hours with a 60-amp continuous rating, rated IP54, built as a custom module with RS485 and CAN reporting. It powers sorting AGVs and swap-bay fleets.
Sorting Floors
Thousands of short moves
A parcel sorting AGV makes a short high-acceleration move every few seconds across a shift. Peak current arrives constantly and the average stays modest. The pack is built for that ratio, and the 120-amp peak covers the acceleration without the board tripping.
Swap Bays
Packs that circulate
A sorting fleet keeps spare packs in a swap bay rather than idling robots on chargers. The pack is dimensioned for that handling, and its interface reports condition to the bay controller before it goes back into a machine.
Cycle Life
Sorting duty, shallow and constant
A sorting AGV makes short moves all shift, never deeply discharging between charges. That pattern is gentle on cells, and a pack rated for 4,000 deep cycles serves a sorting floor for many years before capacity becomes the limit.
Data
Datasheet
| Model | AG48-30 |
|---|---|
| Nominal voltage | 51.2V |
| Capacity | 30Ah |
| Energy | 1536Wh |
| Charge voltage | 58.4V |
| Continuous discharge | 60A |
| Peak discharge | 120A (5s) |
| Cycle life | ≥4,000 cycles @80% DOD |
| Comms | RS485, CAN |
| Weight | ≈13.5 kg |
| Housing | Custom module |
| Operating temperature | Discharge -20~60°C / Charge 0~45°C |
| Protection rating | IP54 |
| Certification | UN38.3 / CE |
Fit
Ordering for a swap bay
Send the bay dimensions, the connector and the protocol the bay controller uses. A swap-bay pack also needs its handling features agreed: guarded contacts, a grip point and a serial the bay can read. Charge at 58.4 volts.
