AGV Series 24V-48V LiFePO4 Battery

Home / Products / AGV / AMR Battery

AGV & Automation

AGV Series

SKU: AGV-24 / AGV-48 (50Ah - 300Ah)

Compact, high-cycle lithium battery designed for automated logistics. Supports 2C charging and smart fleet integration.

6000+ Cycles

2C Fast Charge

Smart BMS

Robust IP65

Request Engineering Data

Built for 24/7 Automation

The AGV Series is specifically engineered for the high-frequency charge/discharge demands of automated guided vehicles (AGVs) and autonomous mobile robots (AMRs).

The battery communicates directly with your AGV host controller or robot fleet management system (FMS), providing real-time data on State of Charge (SOC), State of Health (SOH), and temperature, enabling predictive maintenance.

Designed for space-constrained robot chassis, the AGV series offers flexible form factors and high energy density, minimizing the footprint while maximizing operational range.

Opportunity Charging Ready

Supports fast charging up to 2C. AGVs can recharge in minutes during brief stops or task completions without battery degradation.

High Vibration Resistance

Internal structure is reinforced with shock-absorbing materials to withstand the constant vibration and impacts of warehouse operations.

Extended Lifecycle

Engineered for 6,000+ cycles at 80% DOD, significantly outlasting lead-acid and reducing total cost of ownership in automated fleets.

Technical Specifications

Specification	Value (AGV-24/48)
Nominal Voltage	25.6 V / 51.2 V
Capacity Range	50 Ah - 300 Ah (Customizable)
Energy Density	≥ 135 Wh/kg
Continuous Discharge	1C - 2C (Standard)
Peak Discharge (10s)	3C
Charge Rate (Max)	2C (e.g., 100Ah battery charges in 30 mins)
Communication	CAN 2.0B / RS485 / Modbus
BMS Functions	SOC/SOH Reporting, Precharge Control, Cell Balancing, Temp Protection
Operating Temp	Charge: 0°C ~ 45°C \| Discharge: -20°C ~ 60°C
IP Rating	IP65 (Protected against low pressure water jets)
Vibration Resistance	SAE J2380 / UN38.3 Compliant
Dimensions	Customizable (Contact engineering for chassis fit)

System Integration

Our batteries are designed for plug-and-play integration with major AGV controllers. The BMS provides transparent data for fleet management.

Supported Protocols

Standard CAN Open
Standard CAN 2.0B
Industrial Modbus RTU (RS485)
Optional RS232
Custom Client-specific ASCII protocols

Data Reporting

Voltage (Total) 0.1V Accuracy
Current ± 1% Accuracy
SOC (State of Charge) 1% Increment
SOH (State of Health) 1% Increment
Cell Max Temp Real-time
Fault Codes Active / History

* We provide detailed communication registers and integration support for your software engineering team.
