FL-80 Series 80V LiFePO4 Battery

Home / Products / 80V Lithium Battery

Heavy Duty & Industrial

FL-80 Series

SKU: FL-80-600 / FL-80-800 / FL-80-1000

Ultra-high capacity 80V LiFePO4 battery for Class I heavy forklifts and port equipment. IP67 rated for outdoor, wet, and dusty environments.

IP67 Waterproof

600A Discharge

10-Year Life

Replace Diesel

Request Heavy Duty Quote

Unstoppable Power. Outdoor Ready.

The FL-80 Series is built for the most demanding material handling environments. From bustling port terminals to lumber yards exposed to the elements, this battery delivers consistent power where others fail.

Featuring an IP67 ingress protection rating, the FL-80 is completely sealed against dust and water immersion. This eliminates the need for expensive battery storage rooms and allows for outdoor charging capabilities.

With energy storage capabilities up to 80kWh, the FL-80 effectively replaces diesel-powered Class I forklifts, bringing zero-emission operations to heavy industry without sacrificing torque or runtime.

Weatherproof (IP67)

Fully sealed casing withstands rain, snow, and dust. Operate safely in outdoor yards and wash-down bays.

Massive Torque Output

Delivers up to 600A continuous discharge. Handles 5-ton to 10-ton lifts with ease, even on ramps.

Integrated Heating

Optional built-in heating elements allow for safe charging and operation in freezing temperatures down to -30°C.

Technical Specifications

Model	FL-80-600 / FL-80-800 / FL-80-1000
Nominal Voltage	76.8 V / 80 V
Rated Capacity	600 Ah / 800 Ah / 1000 Ah
Energy Storage	46 kWh / 61 kWh / 76 kWh
Chemistry	LiFePO4 (Lithium Iron Phosphate)
Continuous Discharge	0.5C (300A - 500A Standard)
Peak Discharge (10s)	1.2C - 1.5C
Charge Method	CC/CV with CANbus / RS485
Recommended Charger	0.5C Lithium Charger (300A - 500A)
Operating Temp (Charge)	0°C to 55°C (with Heater: -20°C to 55°C)
Operating Temp (Discharge)	-30°C to 65°C
Ingress Protection	IP67 (Dust Tight & Immersion Proof)
Weight	~650kg - ~950kg (Approx. 60% lighter than Lead-Acid)
Warranty	5 Years / 20,000 Hours

Industrial Applications

Port & Terminal

Designed for container handlers and reach stackers exposed to salt spray and heavy loads.

Lumber & Brick

Ideal for outdoor lumber yards and brick plants where durability and weather resistance are mandatory.

Heavy Manufacturing

Powers 8-10 ton forklifts in steel mills and heavy manufacturing facilities with zero emissions.
