The 36V 100Ah Trolling Battery is a 38.4-volt pack of 3,840 watt-hours with a 100-amp continuous rating and a state-of-charge display, rated IP65. It is built for all-day fishing on an aluminium or glass boat.
A Full Day
3,840 watt-hours on the water
A 112-pound motor at 36 volts pulls about 62 amps at full power and a quarter of that at a fishing pace. Across a tournament day of spot-lock holding, repositioning and a few long runs down a bank, the average lands near 15 to 20 amps. 100 amp-hours cover five to six hours of that with reserve, and the pack still holds voltage for the electronics at the end of the day.
The Display
Knowing what is left
Lead batteries give a rough warning through fading motor speed. Lithium holds its voltage almost flat, and that same flat curve makes a voltmeter close to useless as a fuel gauge. The state-of-charge display on this pack reads the coulombs in and out and reports a percentage. An angler can then decide whether to run to the far bank on what is left.
The Install
One case, one circuit
Three lead batteries and their cabling come out, and one 29-kilogram case goes in with a single pair of leads and a breaker sized to the motor. On an aluminium boat that also removes three sets of terminals from a damp bilge, where corrosion usually starts.
Protection
Breaker and cable sizing
A 112-pound motor pulling 62 amps at full power wants a 60 to 70-amp resettable breaker on the positive lead, mounted close to the battery. Size the cable to the run length as well as to the current, since a long bow run needs a heavier gauge than the breaker rating alone suggests. Check the terminal torque after the first tournament.
Data
Datasheet
| Model | DC36-100 |
|---|---|
| Nominal voltage | 38.4V |
| Capacity | 100Ah |
| Energy | 3840Wh |
| Charge voltage | 43.8V |
| Continuous discharge | 100A |
| Peak discharge | 200A (5s) |
| Cycle life | ≥4,000 cycles @80% DOD |
| Display | State of charge |
| Weight | ≈29 kg |
| Dimensions | 522 × 269 × 220 mm |
| Operating temperature | Discharge -20~60°C / Charge 0~45°C |
| Protection rating | IP65 |
| Certification | UN38.3 / CE / FCC / RoHS |
Fit
Charging
Charge at 43.8 volts from a 36-volt lithium charger or an onboard marine charger set to a 36-volt LFP profile. Fit the charger leads on their own circuit so the motor breaker stays clear.
