PJ-24 Series
SKU: PJ-24-60 / PJ-24-80 / PJ-24-120Compact, lightweight 24V LiFePO4 battery with an integrated handle. Designed for electric pallet jacks and walkie stackers.
Work Smarter, Not Harder.
The PJ-24 Series lithium batteries can be removed easily for charging in seconds, thanks to the integrated ergonomic handle.
Designed to fit the tightest battery compartments on walkie stackers and pallet jacks. The rugged plastic/metal alloy casing protects the cells from accidental impacts common in busy loading docks and warehouses.
No more watering, no more acid corrosion on your tray, and no more dead batteries halfway through the shift. Opportunity charging means you can plug in during breaks and keep the jack running continuously.
Integrated Carry Handle
Designed specifically for pallet jacks. Remove the battery in seconds for off-board charging or security.
Drop-in Replacement
Fits Group 27, Group 31, and other standard pallet jack battery slots without modification.
Zero Maintenance
Sealed construction means no checking electrolyte levels. Just plug it in and go.
Technical Specifications
| Specification | Value |
|---|---|
| Model | PJ-24-60 / PJ-24-80 / PJ-24-120 |
| Nominal Voltage | 25.6 V |
| Rated Capacity | 60 Ah / 80 Ah / 120 Ah |
| Energy | 1.53 kWh / 2.04 kWh / 3.07 kWh |
| Chemistry | LiFePO4 (Lithium Iron Phosphate) |
| Continuous Discharge | 60A - 120A |
| Peak Discharge (10s) | 200A |
| Charge Method | Standard 24V Charger (Lithium Profile) |
| Operating Temp | Charge: 0°C~45°C | Discharge: -20°C~60°C |
| Dimensions (Approx.) | Varies by model (Fits standard battery trays) |
| Weight | ~14kg - ~22kg (30kg - 50kg lighter than Lead-Acid) |
| Warranty | 3 Years / 5,000 Hours |
Equipment Compatibility
The PJ-24 Series is compatible with almost all major brands of electric pallet jacks and stackers.
Electric Pallet Jacks
Standard walk-behind pallet jacks. Replaces 1-2 heavy lead-acid blocks.
Walkie Stackers
Compact stackers for low-level lifting. Improves maneuverability.
Tuggers & Tow Tractors
Supports flatbed tuggers for horizontal transport.
